BTF-LIGHTING 5in1 LM053 Tuya Bluetooth Mesh LED Controller SmartLife TuyaSmart APP Control for Dimming CCT RGB RGBW RGBCCT LED Work with WR01RF WR02RF RC02RFB RC03RFB etc RF Remote DC12V DC24V Max 15A

Product Description

Single Color (Monochrome)-2 Pin LED

Parameters:

Model: LM053Product Name: 5 IN 1 Bluetooth Mesh LED ControllerItem size(LxWxH):122x38x22(mm) / 4.9×1.5×0.9(in)RF: 2.4GHzControl Distance: 30m (98.42ft)APP name: Smart Life or Tuya SmartInput voltage: DC12V or DC24V (It depends on what LED strip you use)Output: 6A/Channel (Total Output Max 15A) 12V180W 24V360WWorking Temperature: -20-60℃Compatible LED strip: FCOB COB 3014 5630 3528 2835 5050RGB 5050RGBW 5050RGB+CCT 5050 CCT etcCompatible Remote control :

Remote control series: RC01RFB/RC02RFB/RC03RFB/RC04RFB/RC05RFB etc RF remotePanel series: WR01RF WR02RF Panel remote

CCT Color (Dual white=Warm white+Cool White)-3 Pin LED

Attention:

The working voltage is DC12 or 24V, the controller will be broken if the voltage is higher than 24V.Please check whether the input voltage of the constant voltage power supply is in accordance with the controller, and please check the connection of the cathode and anode.Please don’t use controller around the metal area and high magnetic field, otherwise, it will badly affect the control distance

Package included:

1x 5 in 1 Bluetooth Mesh controller (The LED strip, remote controller or power supply is not included)

RGB/RGBW/RGBCCT LED-4pin 5pin 6pin LED

Button fixation-Fast, Firm and Simple

SET key-Pilot Lamp

Different Pilot Lamp color

1. Long press SET key 3 seconds ,Pilot lamp pureple blink 3 times-Link mode or Unlink mode

2.Short press SET key , White-single color LED strip ,Yellow-CCT LED Strip, Red-RGB LED strip ,Green-RGBW LED strip ,Blue-RGB+CCT LED strip

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Customer Reviews

4.3 out of 5 stars

596

4.3 out of 5 stars

596

—

4.1 out of 5 stars

134

4.3 out of 5 stars

596

Price

$25.99$25.99 $25.99$25.99
— $26.99$26.99 $26.99$26.99

Group Control

✓

✓

✓

✓

✓

Controller
Work with Bluetooth/WiFi/Zigbee Controller Work with Bluetooth/WiFi/Zigbee Controller 2.4GHz RF 2.4GHz 2.4GHz WiFi

Gateway
Philip Hue/Tuya Gateway Philip Hue/Tuya Gateway No need

APP
SmartLife/TuyaSmart Smart Life/Tuya Smart/Philip Hue Smart Life/Tuya Smart

Google Home/Alexa
Need Tuya Gateway Need Tuya Gateway
✓

Product Dimensions ‏ : ‎ 4.8 x 1.5 x 0.87 inches; 0.63 ounces
Item model number ‏ : ‎ LM053
Date First Available ‏ : ‎ December 16, 2021
Manufacturer ‏ : ‎ BTF-LIGHTING Technology CO.,Limited
ASIN ‏ : ‎ B09NQ15B5K
Country of Origin ‏ : ‎ China

5 in 1 Tuya Bluetooth Mesh LED controller. This Controller can control Dimming(single color), CCT(dual white,warm white cold white), RGB, RGBW, RGB + CCT 5 kinds of LED strip. You can click the SET button to switch the output mode according to the type of the LED strips you connecting and choose the corresponding operation interface. Power: 6A/Channel Total output max 15A .DC12V180W DC24V360W.
【Auto-transmitting function】One controller can transmit the signal from the remote control to the another controller within 99ft(30 meters). As long as there is a LED strip controller within 99ft(30 meters), the remote control distance can be limitless.Auto-Synchronization Function.Different controllers can work synchronously when they are started at different times, controlled by the same remote control at the same dynamic mode and with the same speed.
Suitable for the scene without WiFi or the WiFi signal is weak. Compared with WiFi controller, it’s signal transmission is more stable and the connection is more convenient and faster. One remote/smartphone can control multiple controllers simultaneously.Very suitable for yacht, garden, outdoor and other projects.Note: This controller is IP30 Non-waterproof.
【2 control methods】1st:Compatible 2.4GHz RF Remote: WR01RF,WR02RF,RC01RFB,RC02RFB,RC03RFB,RC04RFB,RC05RFB 2nd: Tuya Smart ,Smart Life APP Bluetooth control . Two methods can be used at the same time.
【PWM LED Type】The operating voltage range is DC12V-24V .Without IC chip PWM LED .Single color 2 wires , CCT 3 wires , RGB 4 wires , RGBW 5 wires , RGBCCT 6 wires FCOB 5050 3528 5630 5730 3014 etc LED string strip bulb lamp.Power: 6A/Channel Total output max 15A .DC12V 180W max. DC24V 360W max.
